Dissolution Testers – USP 1/2/5/6
Basic
Trust E 14 Gen 2 (Basic)
Features
Infinity Test
Authority checks
Device checks
Accurate and Complete Copies of Records
Multi-Level Security
Electronic Log Book
Audit Trail
Report
Metadata Storage
LAN
Touch screen
Fingerprint Authentication
| 7" TFT touch screen display |
| LAN connectivity allows central printing |
| Multilevel security with password for 250 users with user programmable role |
| Alphanumeric data entry of product and user details |
| Complies with USP, IP, Ph. Eur. and JP specifications |
| Unique TimeAction™ function which allows media changeover and infinity test run, ideal for sustained and controlled release products |
| Automatic stirrer height positioning for USP 1, 2, 5, 6, intrinsic test methods |
| Easy Snap-Fit shaft locking mechanism for positive engagement and wobble free operation |
| Molded clear water bath |
| Easy to empty and clean water bath with bottom drainage |
| Precise individual vessel centering system |
| Adjustable leveling of instrument |
| Vibration free smooth motorized lift movement |
| Isolated temperature controller and water circulating pump (vibration-free & precise) |
| 1000 programmable products |
| 24 programmable sampling intervals |
| 50000 test report storage |
| Instrument accessories like paddles, baskets, vessels etc. are laser marked with serial numbers |
| Designed to minimize routine validation |
| 10 Programmable report template |
| Report for online validation of test, monograph, error log during the test |
| This format is suitable for pasting into a single column in a spreadsheet program like Excel or Google Sheets. Each line will be placed in a separate cell. |
| Programmable sample volume from 1 ml to 20 ml |
| Power failure detection and auto resume facility |
| Audio - Visual indicator for system status |
| Audit Trials |
| D'light technology enabling audio visual indication of instrument status |
| Data management (back up of Data for individual machine via FTP) |
| E - Signature |
| Auto Dispenser |
| Biometric log in system |
| Disaster management |
| Reports can be saved in the PDF Format via FTP |
| Machine to machine transfer data for product method and Security via FTP |
| Usage history of machine (stirrer, heater, Total number of test performed Etc) |
| Report sorting according to Review By/Approved By/Based on role access |
| View report on Screen |
| Time synchronisation based on NTP, Domain |
| Electrolab user Active/ Inactive permission set by Client |
| Audit modification events Old Data/ New Data |
| on field Software upgradation |
| static / DHCP IP Module |
| Programmable Tolerances for Temperature and RPM |
| Electronic Log book |
Specifications
| Model | TrustE-14 Basic (Gen-2) |
| Speed range | Variable speed from 20 to 300 RPM |
| Speed accuracy | ±0.5 RPM |
| Temperature Range | 20° to 40°C (Extended range 10° to 40°C, 10° to 55°C and 20° to 55°C Optional) |
| Temperature Accuracy | ±0.1°C |
| Display | 7" TFT touch screen display |
| No. of Product | 1000 maximum |
| Sample interval | Maximum 24 of 1 min to 999 hrs, 59 min |
| Printer interface | Serial port (via LAN) post script or embedded thermal printer (optional) |
| Connectivity | Ethernet, RS-232, RS-485 |
| Bath size (L x W x H) | 1135 x 373 x 180 mm |
| Heater | 1 kW/230 VAC, material S.S. 304 with sensor |
| Dimensions (L x W x H) | 1150 x 521 x 685 mm |
| Weight | 126Kg |
| Electric Power | 220/230 VAC, 50/60 Hz, 1.3 kW/6 Amp / 110 VAC, 50/60 Hz, 1.3 kW/10 Amp |
| No. of Methods | 1000 Maximum |
| No. of Reports | 50000 Maximum |
| No. of Audit Trial | 200000 Maximum |
| Time Range | 1 min to 999 hrs, 59 min |
Ordering Information
| Product | ||
| Product code | Description | Quantity |
| Tablet Dissolution Tester Trust E-14 Gen2 Basic 230Volts | 01413500 | 1 |
[table “162” not found /]
