Dissolution Testers – USP 1/2/5/6
TrustE- 208 Basic (2 Litre)
Features
21 CFR
Benefits
60% savings
Device Checks
Accurate and Complete Copies of Records
Dilution with Stirring
Audit Trail
Electronic Log Book
Authority Checks
Fingerprint Authentication
Infinity Test
IntegrOS
Multi-Level Security
Isolated Temperature Controller
Multi-stage Filtration
LAN
Print Report
Snap-Fit Shaft
Limited System Access
Quality by Design
Touch Screen
Metadata Storage
Rinsing
Motorized Lift Mechanism
Sample Collector Tray
| 7" TFT touch screen display |
| LAN connectivity allows central printing |
| Multilevel security with password for 250 users with user programmable role |
| Alphanumeric data entry of product and user details |
| Complies with USP, IP, Ph. Eur. and JP specifications |
| Unique TimeAction™ function which allows media changeover and infinity test run, ideal for sustained and controlled release products |
| Programmable different aliquot volume for each sample Interval allows variable dilution |
| Automatic stirrer height positioning for USP 1, 2, 5, 6, intrinsic test methods |
| Easy Snap-Fit shaft locking mechanism for positive engagement and wobble free operation |
| Molded clear water bath |
| Easy to empty and clean water bath with bottom drainage |
| Precise individual vessel centering system |
| Adjustable leveling of instrument |
| Vibration free smooth motorized lift movement |
| Isolated temperature controller and water circulating pump (vibration-free & precise) with wake up and sleep modes which saves time and energy |
| 1000 programmable products |
| 24 programmable sampling interval |
| 10000 test report storage |
| Instrument accessories like paddles, baskets, vessels etc. are laser marked with serial numbers |
| Designed to minimize routine validation |
| Programmable report template |
| Report for online validation of test, monograph, error log during the test |
| Programmable sample volume from 1 ml to 20 ml |
| Audit trial |
| Power failure detection and auto recovery facility |
| Delight technology enabling audio visual indication of instrument status |
| E-signature |
| 250 Users |
| Finger print Module |
Specifications
| Model | TrustE-08 Basic |
| No. of station | 8 |
| Speed range | 20 RPM to 300 RPM |
| Speed accuracy | ±0.5 RPM |
| Temperature range | 20°C to 40°C (extended 10°C to 40°C and 20°C to 55°C optional) |
| Temperature accuracy | ±0.1°C |
| Display resolution | 0.1°C |
| Product storage | 1000 |
| Display | 7" TFT touch screen display |
| Test Report storage | 10,000 |
| Sample interval | 1 min to 999 hrs, 59 min |
| Interface port | Ethernet, RS-232, RS-485 |
| Temperature controller | Heater: 1kW, SS 316 with thermal protection |
| Stirrer drive | High performance BLDC drive (maintenance-free) |
| Vessel capacity | 150ml, 250ml, 1L, 2L |
| Water bath | One piece moulded clear |
| Bath capacity | 28 L |
| Dimensions (W x L x H) | 517 mm x 712mm x 690 mm |
| Weight | 90 Kg |
| Electrical power | 220/230 VAC, 50/60 Hz, 1.3 kW/6 Amp 110 VAC, 50/60 Hz, 1.3 kW/6 Amp |
Ordering Information
| Product | ||
| Product code | Description | Quantity |
| 0126804 | Trusté-08 (Basic) - 230V | 1 |
| 0116804 | Trusté-08 (Basic) - 110V | 1 |
| Standard Accessories | ||
| Part number | Description | Quantity |
| 0105A00075 | EDT laser marked basket mesh 40 (Set of 6) | 1 |
| 0104A00066 | EDT basket rod | 8 |
| 0104A00818 | Secure Clip Basket Holder | 6 |
| 0104A00152 | EDT Moulded Tray For Basket, Basket Holder & Rod | 1 |
| 0122A00003 | EDT Laser Marked Paddles For 2 Ltr Glass Vessel | 1 |
| 0104A00093 | EDT Moulded Tray For Paddles | 1 |
| 0122A00001 | EDT Laser Marked Glass Vessel 2 Ltr Clear | 1 |
| IntegrOS Lite Version | 1 | |
| 01048V4114 | EDT-Lx V-4 Temperature Controller ETC-15 | 1 |
| 0104A00610 | Stirrer for replenishment | 2 |
| 0104BV4155 | EDT V-5 External Probe Without Trim Pot | 1 |
